MIL-F-85668 Fire System, 20-Millimetre Point And Suppressive Helicopter, Ah-It \(Tow\), A/A49E-7\(V4\)This specification establishes the requirements for performance, design, test, manufacture, and acceptance of the A/A49E-7\(V4\) AH-1T \(TOW\) Helicopter 20-Millimetre \(mm\) Point and Suppressive Fire System, hereinafter referred to as the system.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15 - 16 - 17


MIL-F-85668(AS)
TABLE II.
Physical interface requirements - Continued
Drawing
Component
152D5403
Pressure Transducer
218F330
Recoil Adapter
218F331
Ammunition Feed System
152D5402
Slider Assembly
197C7326
Torque Box assembly
197c7325
Coincidence Control Box
3.1.3 Major component list.  The major components of the system, Drawing
209F115, shall be as specified in Table III.
TABLE III.
Major component list.
Drawing
Major Component
201F798
Turret Assembly
189F901
Gun Control Assembly
201F799
Gun Drive Assembly
201F525
Turret Control Assembly
116C3555
Pressure Transducer
105D3853
Recoil Adapter
5
